Teardrop 48 x 192 Storage Rack Upright Frames
FOB Oregon Warehouse
Stock color: Vista Green
Combine Beams and Frames for maximum discount!
Many Other Sizes are Available!
High-grade steel racks for a low price. Interchangeable with most teardrop designs, such as Equipto, Frick-Gallagher, Speedrack and more (see graphic for complete list). 2" vertical adjustment step beam design and reinforced struts, columns and guards.
We can design and build racking systems to fit your operation. Custom height or depth frames available.
- Quick shipment available on the common sizes.
- Adjusts on 2" centers.
- 5"x8"x3/8" seismic plates are standard with 4 holes.
- We build and design racking systems to your operation.
- Note: Upright frame capacities are based on 42" maximum vertical beam spacing.
How to Select Your Pallet Rack
1. Frame Capacity
Add total weight of all pallets for each bay (exclude pallets on floor).
Measure all verticals including height of pallet, pallet load and beam height, add 4" clearance between top of load and bottom of beam above. Top beam should be a minimum of 6" less than maximum lifting height of your forklift.
Pallet should overhang frame by 3" front and back (48" pallet, use 42" deep frame). Deduct 6" from pallet depth. Pallets need to be in good condition.
Measure width of pallet, add a minimum of 3" pallet-to-frame clearance and 4" between pallets to determine correct beam length. Each pair of beams must support weight of pallets per level. Add-on sections require only one additional frame and required number of beams.
